Fuel, filling
WARNING
Risk of fire and explosion.
A running auxiliary heater during fuel filling could cause fire and
explosion.
Swit
c
ch o
f
f
f
f t
h
h
e
e a
u
u
x
xi
l
l
i
i
a
a
r
ry h
e
eat
e
e
r
r b
e
e
f
f
o
o
r
re f
i
il
l
l
i
ing f
u
ue
l
l.
If the machine is laid up for a longer period, the tank ought to be
completely full with fuel to prevent corrosion of the insides of the
tank.
N
O
O
T
T
E
E!
Do not fill any other liquids than fuel in the fuel tank!
M
a
a
n
n
u
u
a
a
l
l f
u
u
e
e
l
l f
i
i
l
l
l
l
i
i
n
n
g
g
1 Clean the area around fuel filler cap (A).
2 Open the filler cap and fill fuel.
Fu
e
e
l
l f
i
i
l
l
l
l
i
i
n
n
g
g w
i
i
t
t
h
h b
u
u
i
i
l
l
t
t
-
-
i
i
n
n p
u
u
m
m
p
p
Fuel filling can also be done with an electrical pump under the fuel
tank, which is provided with an electronic overfilling protection.
The inlet side of the pump is connected to a suction pipe via a
hose. At the outer end of the pipe there is an inlet strainer.
1 Fold down the cover under the fuel tank.
2 Put the hose in the fuel barrel.
3 Start the pump by pressing green button (B).
When the tank is full, the pump stops automatically.
4 If you would like to interrupt the filling, press red button (C).
5 When filling is done with the manual filling button (D) the button
must be pressed the whole time.
The pump will stop when releasing the button.
N
O
O
T
T
E
E!
When using the manual filling button (D) the pump will not stop
automatically when the tank is full.
F
u
ue
l
l t
a
a
n
nk ca
p
p
a
a
c
ci
t
t
y
y: se
e
e specif
i
icat
i
i
o
on
s
s ch
a
a
p
p
t
t
e
er
A
V1148055
A. Fuel filler cab
V1161685
BC
D
Fuel filling pump
B. Green button, start
C. Red button, stop
D. Manual filling button
