Volvo EW160E - Lifting Capacities

L
Lifting capacities
At the dipper arm end, without bucket.
Unit for weights: 1000 kg (2205 lb)
For lifting capacity including bucket, simply subtract actual weight
of bucket for the values.
Unit for length: 1 m (3.3 ft)
B
A
L
d=
u=
V1152572
a=
b=
A = Reach from machine centre
B = Lifting hook related to ground level (m)
L = Dipper arm length
a = Superstructure across undercarriage
b = Superstructure along undercarriage
u = Support up
d = Support down
Max. = Maximum reach / maximum high
*** = Grab arm
Working pressure with power boost.
The values are in compliance with ISO standard 10 567. They do
not exceed 87% of hydraulic lifting capacity or 75% of tipping load,
with the machine on firm, level ground.
Load capacities marked with an asterisk (*) are limited by machine
´s hydraulic lifting capacity rather than tipping load.
