Volvo EW160E - Instrument Panel Overview

I
Instrument panels
Carefully read through this Operator’s Manual and keep it in the
cab so that it is always available.
N
O
O
T
T
E
E
!
!
Do not operate the machine until you know the function and
position of the instruments and operating controls. Always ensure
that the seat belt is fastened before starting the machine.
V1147241
1 Instrument panel, left
2 Instrument panel, right
3 Instrument panel, front (Instrument Cluster)
4 Instrument panel, rear
