H
A
2438 mm (8 ft)
B
V1147026
C
F
G
D
E
c
b
a
H
A
C
F
V1147027
E
EW180E
Two-piece boom
5.5 m (18 ft 0.5 in)
Quick coupler S1 -
Bucket V4_GP Clamsh ell
Dipper arm a
2.45 m
(8 ft 0.5 in)
b
2.6 m
(8 ft 6.4 in)
c
3 m
(9 ft 10.1 in))
3.2 m*
(10 ft 6 i
n
n*)
A. Max. digging reach 9766 mm
(32 ft 0.5 in)
9912 mm
(32 ft 6.2 in)
10302 mm
(33 ft 9.6 in)
8837 mm
(28 ft 11.9 in)
B. Max. digging reach at ground level 9588 mm
(31 ft 5.5 in)
9737 mm
(31 ft 11.4 in)
10134 mm
(33 ft 3 in)
-
C. Max. digging depth 5855 mm
(19 ft 2.5 in)
6005 mm
(19 ft 8.4 in)
6405 mm
(21 ft 0.2 in)
4981 mm
(16 ft 4.1 in)
D. Max. digging depth at 2438 mm (8 ft) level 5760 mm
(18 ft 10.8 in)
5912 mm
(19 ft 4.8 in)
6316 mm
(20 ft 8.7 in)
-
E. Max. vertical wall digging depth 4738 mm
(15 ft 6.5 in)
4900 mm
(16 ft 0.9 in)
5276 mm
(17 ft 3.7 in)
-
F. Max. cutting height 10846 mm
(35 ft 7 in)
10973 mm
(36 ft 0 in)
11312 mm
(37 ft 1.4 in)
9749 mm
(31 ft 11.8 in)
G. Max. dumping height 7647 mm
(25 ft 1.1 in)
7777 mm
(25 ft 6.2 in)
8115 mm
(26 ft 7.5 in)
-
H. Min. front slew radius 3006 mm
(9 ft 10.4 in)
3072 mm
(10 ft 1 in)
3244 mm
(10 ft 7.7 in)
3690 mm
(12 ft 1.3 in)
* dipper arm for grab
