5
Stop
9/16"
1-1/8"
3/8"
1/8"
Latch case
5/8"
Strike
C
1/4"
1"
2-3/4"
L
Install bottom strike or
prepare threshold.
Install top strike and
ratchet release.
338 Top strike
See “Frame Preparation” on
page 7 for cut-out and holes
Ratchet release
Strike
Shim
(if needed)
Spacer
(use when frame
has no door stop)
385-A Bottom strike
Threshold application
Flat threshold
application
I
J
See “Frame Preparation”
on page 7 for holes
Note: Thresholds are not to
be used with 38/3947-F
Rounded
edge
385-A strike has two pieces.
Grout bottom piece into floor
and attach top piece to bottom
with screw through slot.
C
L
Remove material
as necessary to
accommodate
latch bolt throw
5/8"
3/32"
R max.
1-1/8"
Secure device to door and
mount door to frame.
B
A
#425 Sex bolts
(required)
#325 Sex
bolts
or trim
lauqe eciveD
ot thgieh
fo mottob
no rood
dne hcae
Bottom of door
Mark and prepare 2
mounting bracket holes
1/4” drill inside
13/32” drill outside
Install tailpiece guide and
attach rods to center case.
Place device over L- brackets and install adjusting
screws, then install retainers and locking screws
G
H
Adjusting
screws
Locking
screws
Retainers
Rotate tailpiece
guide to match
tailpiece
*Tailpiece
Tailpiece
guide
Cut tailpiece
if needed
1/8”
Door
surface
* Tailpiece is attached to
trim or cylinder depending
on application
9
11
10
12
To Next Page
