60
WWW.VORONDESIGN.COM
M5x30 BHCS
GT 20T Idler
DON’T OVER TIGHTEN
The screw is used to
position the idler and
is screwed directly into
plastic.
The idler must spin freely.
LEFT XY JOINT
