68
WWW.VORONDESIGN.COM
Inductive Probe
M3x20 SHCS
Heat Set Insert
X CARRIAGE
PROBE WIRES
Cut the probes wires to about
15cm.
ENDSTOP WIRES
Place the endstop wires into
the same channel.
