85
WWW.VORONDESIGN.COM
CLOCKWORK
BMG Drive Pinion
Stepper Motor
M3x8 SHCS
STEPPER WIRES
If the steppers has wires cut them
to approximately 150mm.
Wires/connector to the right hand
side.
