92
WWW.VORONDESIGN.COM
FAN ASSEMBLY
M3x16 SHCS
DON’T OVER TIGHTEN
The screws are screwd
directly into plastic.
REMOVE TOP COVER
Split the fan open by
bending the taps on the
side.
