WWW.VORONDESIGN.COM
CAD version: ERCF V2
FINAL ASSEMBLY
B
A
C
B
E
1x Drag Chain
4x M3x8mm FHCS
2x M5 Locking Nut
2x M5x30mm SHCS
A
B
C
D
FINAL ASSEMBLY SUB-BOM
115115
EXPLODED VIEW
