VORON ERCF v2 - Page 83

WWW.VORONDESIGN.COM
CAD version: ERCF V2
8383
SELECTOR
LM8UU or RJ4JP-01-08
BEARING INSERTION
Using a soft jaw vice or flat object, carefully
press-fit the bearings into their holes. They
should be flush with the print bed side of the
Selector_Cart.
SELECTOR CART BEARINGS
