CAD version: ERCF V2
8585
SELECTOR
M3 Heat Set Insert
HEATSET INSERTION
This heatset insert is a tricky one. Take your time.
It may help to use a screw to pull from the
opposite side during insertion.
If you wind up melting the spring hole, either
reprint the piece and try again, or clean up the
hole with a drill bit. The bore size is 6.6mm, so
use 6mm, ¼”, or 17/64” sized bits.
SELECTOR CART SPRING HEATSET
HEAT SET INSERTS
The list of pages with heat set inserts is on Page 15.
