19
WWW.VORONDESIGN.COM
MR85 Bearing
MOTOR PLATE
BEARING FIT
Fully seat the bearing into the plastic pocket.
Apply even pressure to insert them. Avoid
pressing on the inner ring of the bearing.
If the t is too tight the printed parts are
likely over-extruded.
MR85 Bearing
CHECK BEARING FIT
The bearings must slip on and off the shaft
easily to allow the gear to self-centre.
Pressing the bearings on the shaft will
damage them.
Lightly sand the shaft if required.
