VORON STEALTHBURNER - Free Movement and Tension Adjustment

27
WWW.VORONDESIGN.COM
TENSION MECHANSIM
TENSION KNOB
Turning the thumb screw clockwise will increase the
tension and grip on the lament. Too much tension
will result in print issues.
ANTI SQUISH THINGYMAJIG
Softer and exible materials will deform
and extrude poorly under too much tension.
ClockWork2 adds an adjustment feature to set the
minimum distance between the drive gear and
the idler, limiting the squish on the lament, and
to prevent the gears from meshing too tightly or
binding up the extruder.
