34
WWW.VORONDESIGN.COM
ACCESS HOLE
The bolt drive can be accessed from the
front of the extruder.
DON’T OVER-TIGHTEN
The bolt is threaded directly
into plastic.
M3x6 BHCS
CABLE COVER
