119
WWW.VORONDESIGN.COM
24V PSU
CONTROLLER BOARD
The assembly manual will outline the wiring for a BTT
SKR Mini E3 2.0. You can nd additional documentation
and alternative congurations on
docs.vorondesign.com
Raspberry Pi
PWR IN
+ -
DC POWER
