135
WWW.VORONDESIGN.COM
Controller
BED HEATER WIRING
Attach the cables for the bed
heater from the sides. Use low
prole bolts to secure the ring
terminals to the heater.
HEATED BED
M3 Nut
M3x8 Low Prole
Ring Terminal
