30
WWW.VORONDESIGN.COM
Heat Set Insert
Microswitch
M2x10 Self Tapping
SOLDER WIRES
Solder approx. 100mm of
wire to the mircoswitch
before installing it.
See setup guide for details.
Y BELT HOLDER - MICROSWITCH
