56
WWW.VORONDESIGN.COM
M5x40 SHCS
X AXIS
X AXIS INSTALLATION
Lightly tighten the M5x40 bolts and
align the X axis horizontally by moving
it all the way to the top. Make sure it is
centered across the front.
Hold the X axis against the stoppers and
fully tighten the bolts. Move the axis up
and down and check for binding.
