82
WWW.VORONDESIGN.COM
CLOCKWORK
BMG Drive Gear
MR85 Bearing
CHECK BEARING FIT
The bearings must slip on and off the shaft
easily to allow the gear to self centre. Do not
shim into position.
Pressing the bearings on the shaft will
damage them.
Lightly sand the shaft if required.
CHECK PLACEMENT
Make sure the lament drive gear
is fully seated against the drive
shaft gear.
To Next Page
