Vortex Ranger 1000 User Manual

2 3
2 3
Loop Lanyard
through Attachment
Sockets
Measure Button
Adjust
Focus with
Eyecup
Battery
Compartment
Utility Clip
(Attaches to Either Side)
Menu Button
BASIC OPERATION
Install Battery
Open the battery
compartment and
install the CR2 battery
included with the
Ranger 1000.
Power Up
With the battery installed, the Ranger 1000 is in a Ready
Condition—the normal power-off condition when not ranging. To
power up the Ranger 1000 from Ready Condition
and prepare for ranging, press and release the
Measure button. The HCD or LOS ranging
screen will display. The Ranger 1000 will power
down automatically after ten seconds of non-use.
Turn the eyecup in or out until image is sharp.
Tripod
Socket
Battery
Power Indicator
Remove battery
compartment cover.
Install battery with
positive side facing
outwards.
+
–
Focus
