Vortex RANGER 1300 User Manual

5 4
RANGER
®
13 0 0
LASER RANGEFINDER
Lanyard
Attachment
Sockets
Measure Button
Adjust Focus
with Eyecup
Battery
Compartment
Utility Clip
(Attaches to Either Side)
Menu Button
Battery Installation
Open the battery compartment
and install the CR2 battery
included with the Ranger
®
.
Powering On/Off
Once the battery is installed,
the Ranger
®
1300 is in Ready
Condition—the normal power-off
condition when not ranging. To
power up the Ranger
®
1300 from
Ready Condition and prepare for
ranging, press and release the
Measure button. The HCD or LOS
ranging screen will display. The
Ranger
®
1300 will power down
automatically after ten seconds
of non-use.
Focus
Turn the eyecup in or out until
image is sharp.
Battery
Power Indicator
Remove
battery
compartment
cover.
Install battery with positive
side facing outwards.
The Ranger
®
1300 Rangefinder

Vortex RANGER 1300 Specifications

General

Magnification	6x
Objective Lens Diameter	22 mm
Max Range	1300 yards
Eye Relief	15 mm
Weight	7.7 oz
Battery	CR2
Ranging Distance (Reflective)	1300 yards
Length	3.9 inches
Width	3 inches
Field of View (Degrees)	6 degrees
Waterproof	Yes
Fogproof	Yes
Lens Coating	Fully Multi-Coated
Prism System	Roof
Field of View	315 ft @ 1000 yds
Max Angle Reading	± 60 degrees
Accuracy	± 1 yard @ <100 yards ± 2 yard @ 100-499 yards ± 3 yard @ 500-999 yards
