PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
PART - 7.
10
11
12
3
4
5
6
7
B
8
9
A
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
A) Refrigerator compartment
B) Freezer compartment
1) Thermostat knob
2) Refrigerator lamp & cover
3) Refrigerator shelves
4) Crispers cover
5) Crisper
6) Freezer room cover
7) Freezer comp. drawers
8) Bottle shelf
9) Door shelves
10) Egg holder
11) Ice tray
12) Plastic ice blade *
* In some models
1
2
General notes:
Fresh Food Compartment (Fridge): Most e󰀩cient use of energy is ensured in the
conguration with the drawers in the bottom part of the appliance, and shelves evenly
distributed, position of door bins does not a󰀨ect energy consumption.
Freezer Compartment (Freezer): Most E󰀩cient use of energy is ensured in the
conguration with the drawers and bins are on stock position.
