17
9 REPLACEMENT OF LAMPS
A DANGER
Disconnect the electrical supply of the cooker
hood. Leave the lamps to cool down rst be-
cause they could burn your hands when they
are hot.
9.1 Replacement of Halogen Lamp
Fig. 13: Replacement of LED Lamp
Remove the aluminium cartridge lter. Remove
the faulty bulb and replace with a new one with
the same rating. Fig. 13
9.2 Replacement of Spark Plug
Lamp
Fig. 14: Replacement of Spark Plug Lamp
Remove the aluminium cartridge lter. Remove
the faulty bulb and replace with a new one with
the same rating.Fig. 14
9.3 1W Replacement of LED Lamp
• Disconnect the electrical connection of
LED lamp.
• Push on the lamp with your hand, to re-
move it.
• Separate the self adhesive tape around the
lamps and the body plate from each other.
• Before placing the new LED lamp, remove
the protective folio from the frame, and
then stick it on its place on the body of the
product.
