Vox Tonelab ST Service Manual

1/2
VOX ToneLab ST Parts List
Part Number Category Part Name Location Reference Q'TY
500320012334 DSP MB87R1420PMC-G-BND
FRONT REAR PCB
IC14 1
500320011256 CPU
M38039GCH-509HP U0
FRONT REAR PCB
IC9 1
500324022114 USB/1394 IC TAS1020BPFBR
FRONT REAR PCB
IC10 1
500324018021 A/D Converter AK5358AET-E2
FRONT REAR PCB
IC4 IC11 2
500324018020 D/A Converter AK4384ET-E2
FRONT REAR PCB
IC6 IC16 2
500320049013 EEPROM M24C64-WDW6TP (X07500)
FRONT REAR PCB
IC17 1
530000001374 EEPROM AK93C75AV
FRONT REAR PCB
IC2 1
530000000183 SRAM IC CS18LV02563AC-70
FRONT REAR PCB
IC5 1
530000000189 RESET IC IC KIA7125FV
FRONT REAR PCB
IC1 1
530000001098 REGULATOR IC UTC UR3325
FRONT REAR PCB
IC8 1
530000001375 REGULATOR IC LM1117MPX-5.0
FRONT REAR PCB
IC15 1
530000001376 REGULATOR IC MC34063AD
FRONT REAR PCB
IC7 1
530000000194 OPAMP IC NJM2872AF
FRONT REAR PCB
IC3 1
530000001377 USB FILTER USBUF01W6
FRONT REAR PCB
IC18 1
530000001378 DIGITAL TR DTA114EUA
FRONT REAR PCB
DT4-7 4
530000001096 DIGITAL TR DTC114EUA
FRONT REAR PCB
DT8 - 15 8
530000001379 TRANSISTOR KTC2025
FRONT REAR PCB
Q6 1
530000000275 TRANSISTOR TR KTC2875
FRONT REAR PCB
Q4,Q5,Q8 3
530000000279 TRANSISTOR TR KTC4075
FRONT REAR PCB
Q2,Q3,Q17 3
530000000271 TRANSISTOR TR KTA2014
FRONT REAR PCB
Q12 1
530000001444 DIODE 1N4148 LL-34 TYPE
FRONT REAR PCB
D1,D2,D3,D7,D11-D14,D16-
D24
17
530000001380 INDUCTOR HH-1M1608-600JT
FRONT REAR PCB
L1-L4,L8-L12, L17, L20-21 12
530000001381 TRIMER VR KVSF689AC503 50k B
FRONT REAR PCB
VR2 1
530000001382
POTENTIONMETER(11C)
VR RV160-40G-13S-B10K-C11(11C)
FRONT REAR PCB
VR4,VR10 2
530000001445
POTENTIONMETER(11C)
VR RV160-40-13S-B10K-C11 (11C)
FRONT REAR PCB
VR12 1
530000001446
POTENTIONMETER
VR RV160-40-13S-B10K-C0
FRONT REAR PCB
VR5 -VR8, VR11,VR14 6
530000001383
POTENTIONMETER
VR RV160-40G-13S-B10K-C0
FRONT REAR PCB
VR9, VR13 2
530000001384
POTENTIONMETER
VR RV1604-12SP-B10K
FRONT REAR PCB
VR16 1
530000000277 TRANSISTOR TR KTC3198GR
FRONT REAR PCB
Q7,Q14 2
530000001385 FET KTK117GR
FRONT REAR PCB
Q1 1
530000001386 DIODE 1SS133
FRONT REAR PCB
D4 1
530000001387 LED(3mm BI-COLOR) 3RG9HW-1-A
FRONT REAR PCB
LED4 1
530000001226 LED SUPPORT LED SUPPORT SW 4009 - 9MM
FRONT REAR PCB
LD4 1
530000001388 LED(3mm RED) 3024SRD4
FRONT REAR PCB
LED9-10,LED12,LED16-18 6
530000001225 LED SUPPORT LED SUPPORT SW 4010 - 10MM
FRONT REAR PCB
LD9-10, LD12, LD16-18 6
530000001389 HLBW240R-AF1
FRONT REAR PCB
LED2 1
530000001390 SEGMENT SUPPORT 5504 - 4MM
FRONT REAR PCB
LD2 4
530000001391 SCHOTTKY DIODE 1N5819
FRONT REAR PCB
SD1 1
530000001203 ZENER DIODE 1N5243B,T
FRONT REAR PCB
ZD1 1
530000000150 DIODE D 1N4002
FRONT REAR PCB
D5,D31 2
530000000158 DC JACK DC JACK HTJ-020-04A
FRONT REAR PCB
U2 1
530000001392 PHONE JACK HTJ-035-19DB
FRONT REAR PCB
J3 1
530000001393 PHONE JACK EPJ-BBB-6.5P
FRONT REAR PCB
J2 1
530000000650 PHONE JACK PHONE JACK EPJ-BNB-6.5MONO
FRONT REAR PCB
J1 1
530000001394 USB JACK USB-B TYPE PCB(F) 90C BLACK
FRONT REAR PCB
CN4 1
530000001087 CRYSTAL CRYSTAL 8.00MHZ
FRONT REAR PCB
X2 1
530000001395 CRYSTAL HC-49US 6.00MHZ
FRONT REAR PCB
X3 1
530000000137 INDUCTOR BEAD CORE SAT2550L
FRONT REAR PCB
L6,L7 2
530000001396 INDUCTOR AL04TO101K
FRONT REAR PCB
L5 1
530000001397 SLIDE SWITCH ASS-2401A(K:7)
FRONT REAR PCB
SW13 1
530000000265 TACT SW TACK SW ATS-1230B (K=9.5MM)
FRONT REAR PCB
SW1,2,4,5,6,8,9,10,12 9
530000001398 FLAT CABLE UL2877 AWG26, 9P, 100MM
FRONT REAR PCB
J14-J15 1
530000001399 HARNESS 5P 150MM, BLK/WHT
FRONT REAR PCB
J40-J41 1
530000001400 HARNESS 10P-5P,100MM, RED/WHT
FRONT REAR PCB
J8-J9 1
530000001401 HARNESS 3P,150MM, BLK/WHT
FRONT REAR PCB
J16-J17,J42-J43 2
530000001402 HARNESS 3P, 200MM, BLK/WHT
FRONT REAR PCB
J4-J5 1
530000001403 HARNESS 3P, 100MM, BLK/WHT
FRONT REAR PCB
J30-J31 1
530000001404 HARNESS 2P, 100MM, RED/BLK
FRONT REAR PCB
J6-J7 1
530000001405 CONNECTOR LWL0640 2PIN
FRONT REAR PCB
J32 1
530000000623 PCB BRACKET
FRONT REAR PCB
PRE0031 2
530000000282 VACUUM TUBE VACUUME TUBE 12AX7EH
PEDAL FOOT PCB
Q15 1
530000001406 TUBE SOCKET GZC9-Y 9P(D)
PEDAL FOOT PCB
V1 1
530000001407 LED(3mm RED) 3024SRD4
PEDAL FOOT PCB
LED5-6,LED14-15 4
530000001408 LED(3mm ORANGE) 3024SOD
PEDAL FOOT PCB
LED1 1
530000001409 LED(5mm GREEN) 5013SGD4
PEDAL FOOT PCB
LED11 1
530000001410 LED(5mm RED LED) 5014SRD4
PEDAL FOOT PCB
LED13 1
530000001411 LED SUPPORT 5519 - 19MM
PEDAL FOOT PCB
LD5-6, LD14-15 4

Vox Tonelab ST Specifications

General

USB	No
MIDI	No
Power Supply	DC 9V
Effect Types	33
Amp Models	11
Inputs	1 x Instrument
Expression Pedal	Built-in
Outputs	1/4" line/headphone jack, 1/4" amp/line out jack
