10
In Effect On/Off mode, these switches individually switch the Pedal, Modula-
tion, Delay, and Reverb effects on/off.
6.3 A/B ch channel select pedal, Channel LEDs
Use this to change channels within the currently selected program. The chan-
nel LEDs located above the pedal will light accordingly (green when channel A
is selected, red when channel B is selected).
FX ON/OFF SWITCH
Press this switch when you want to switch to Effect On/Off mode and the LED
at the upper left of the pedal will light.
In Effect On/Off mode you can use the program select pedals to individually
switch the Pedal, Modulation, Delay, and Reverb effects on/off.
If you press and hold this switch for 0.5 seconds or longer, the output will be
bypassed. If you press and hold this pedal for one second or longer, the output
will be muted. The tuner will operate when ToneLabSE is bypassed or muted.
To cancel bypass or mute (Tuner), press this switch once again.
EFFECT CONTROL SECTION
8.1 CONTROL (Control switch)
This pedal controls the effect function specified by the Control switch setting.
8.2 EXP1, EXP2 (Expression pedal 1, Expression pedal 2)
These pedals control the effect parameter you assigned as the expression
pedal setting; e.g., volume, wah, or other effect parameter. Pressing down
firmly on an expression pedal will activate a switch underneath the pedal, let-
ting you turn the assigned effect on/off (except when you’ve assigned volume
or an amp parameter).
VALVE
9.1 Valve window
ToneLabSE contains a 12AX7 (ECC83) valve (“vacuum tube”).
NOTE: The valve cover and or valve may break if it’s subjected to impact. If the
valve cover breaks, please have it replaced; leaving a damaged cover may lead to
the valve itself to become damaged.
7
8
9
