VTech CM18245 - Deskset Installation

4
Getting started
Deskset installation
1. Install the mounting bracket for tabletop use.
Low tabletop position: Insert the fixed tabs of the mounting bracket into slots
A
and
B
. Press the flexible tabs into slots
C
and
D
until they click into place.
High tabletop position: Insert the fixed tabs of the mounting bracket into slots
A
and
B
. Press the flexible tabs into slots
C
and
D
until they click into place.
Low tabletop position
High tabletop position
B
B
A
A
C
C
D
D
D
D
C D
A B
B
B
