8
Getting started
Deskset installation
After the deskset is powered up, it takes at least one minute for the deskset
to start up the system and the screen displays booting.... during startup.
The deskset is set to obtain IP address automatically by default. The screen
displays Obtaining IP from DHCP server Please wait... when the deskset
is obtaining IP from the Ethernet switch or router. When an IP is obtained, the
screen displays IP obtained: XXX.XXX.X.XXX Press SELECT to proceed.
If the deskset cannot obtain the IP address automatically, it displays No IP
assigned. Check network. and then the Network setup menu. You need to
enter the IP address manually under the Set static IP menu. See To set static
IP when initially setting up the deskset section in the online complete user’s
manual for details.
To connect the deskset to the UP416 console:
1. When the deskset displays IP obtained: XXX.
XXX.X.XXX Press SELECT to proceed, press
MENU/SELECT.
2. The deskset displays Enter the name of the
Console connecting to this phone. Press
MENU/SELECT.
3. The deskset displays Console’s name. The console’s
name is set as Console by default. If you have
changed your console’s name, enter the same name
using dialing keys on the deskset. Otherwise, skip to
step 4 to continue.
• Press DELETE to delete a character.
• Press /REPEAT or /SKIP to move the cursor left
or right.
• Press 0 to add a space.
When you finish editing, press MENU/SELECT to save.
4. The deskset screen displays Please set an
extension number to this phone. Press
MENU/SELECT to continue.
5. Press /REPEAT or /SKIP to choose the desired
extension number. The extension number ranges from
11 to 26. Press MENU/SELECT to save.
(Continued on next page)
IP obtained:
XXX.XXX.X.XXX
Press SELECT
to proceed
Enter the name
of the Console
connecting to
this phone.
Please set an
extension number
to this phone.
Set Ext No.
12
Console’s name:
Console_
To Next Page
