VTech i5871 - Base Unit Layout

www.vtechphones.com
12
Telephone settings
Base unit layout
3
4
8
7
6
9
10
11
12 13
17
15
16
5
2
1
18
14
1. LCD display
2. Softkeys
3. SPEAKERPHONE
4. DELETE
5. REPEAT
6. PLAY/STOP
7. SKIP
8. CLEAR
9. VOLUME
10. INTERCOM
11. New message LED
12. Antenna
13. Charging LED
14. Speaker
15. Microphone
16. Telephone jack
17. DC connector jack
18. Spare battery
compartment
