18
Lift the kickstand as indicated by the arrows below to release it from
the grooves.
3.
To mount the console on the wall
Unplug the power adapter from the outlet, the telephone line cords from the
wall jacks (or DSL filters), and the Ethernet cable from the Ethernet switch
or router.
Put the corded handset aside. Use a coin to rotate the handset tab 180
degrees. The protruding edge holds the corded handset when the phone is
mounted on the wall.
1.
2.
Protruding edge
Handset tab
Getting started
Wall mount installation
