AC VOLTAGE – 5 ½ DIGITS – 1 YEAR ACCURACY
RANGE
RESOLUTION
FREQUENCY
RANGE
0 °C TO +55 °C
READING
ACCURACY
READING
ACCURACY
100 mV
1µV
20 Hz - 45 Hz
< 30 mV
378 µV
> 30 mV
2.28 mV
>45 Hz - 100 Hz
198 µV
1.23 mV
>100 Hz - 20 kHz
198 µV
0.84 mV
>20 kHz - 100 kHz
285 µV
2.85 mV
1 V
1 0µV
20 Hz - 45 Hz
< 300 mV
2.28 mV
> 300 mV
22.8 mV
>45 Hz - 100 Hz
1.23 mV
12.3 mV
>100 Hz - 20 kHz
0.84 mV
8.4 mV
>20 kHz - 100 kHz
2.85 mV
28.5 mV
10 V
10 0µV
20 Hz - 45 Hz
< 3 V
22.8 mV
> 3 V
228 mV
>45 Hz - 100 Hz
12.3 mV
123 mV
>100 Hz - 20 kHz
8.4 mV
84 mV
>20 kHz - 100 kHz
28.5 mV
285 mV
100 V
1mV
20 Hz - 45 Hz
< 30 V
228 mV
> 30 V
3.63 V
>45 Hz - 100 Hz
123 mV
1.83 V
>100 Hz - 20 kHz
84 mV
1.02 V
>20 kHz - 100 kHz
285 mV
3.78 V
300 V
1 mV
20 Hz - 45 Hz
< 300 V
3.63 V
>45 Hz - 100 Hz
1.83 V
>100 Hz - 20 kHz
1.02 V
>20 kHz - 100 kHz
3.78 V
Specifications are for sine wave input > 5% of range for 100 mV – 100 V ranges, >15% for 300 V range, with High AC filter selected.
Volt-hertz product is limited to 1.5x10
7
V•Hz.
Over-range: 20% beyond range, except 300 V range.
Input Impedance: 1 MΩ  2% in parallel with < 100 pF.
AC VOLTAGE – 4 ½ DIGITS – 1 YEAR ACCURACY
RANGE
RESOLUTION
FREQUENCY
RANGE
0 °C TO 55 °C
READING
ACCURACY
READING
ACCURACY
100 mV
10 µV
20 Hz - 45 Hz
< 30 mV
381 µV
> 30 mV
2.31 mV
>45 Hz - 100 Hz
201 µV
1.26 mV
>100 Hz - 20 kHz
201 µV
0.87 mV
>20 kHz - 100 kHz
288 µV
2.88 mV
1 V
100 µV
20 Hz - 45 Hz
< 300 mV
2.31 mV
> 300 mV
23.1 mV
>45 Hz - 100 Hz
1.26 mV
12.6 mV
>100 Hz - 20 kHz
0.87 mV
8.7 mV
>20 kHz - 100 kHz
2.88 mV
28.8 mV
10 V
1mV
20 Hz - 45 Hz
< 3 V
23.1 mV
> 3 V
231 mV
>45 Hz - 100 Hz
12.6 mV
126 mV
>100 Hz - 20 kHz
8.7 mV
87 mV
>20 kHz - 100 kHz
28.8 mV
288 mV
100 V
10 mV
20 Hz - 45 Hz
< 30 V
231 mV
> 30 V
3.66 V
>45 Hz - 100 Hz
126 mV
1.86 V
>100 Hz - 20 kHz
87 mV
1.05 V
>20 kHz - 100 kHz
288 mV
3.81 V
300 V
10 mV
20 Hz - 45 Hz
< 300 V
3.66 V
>45 Hz - 100 Hz
1.86 V
>100 Hz - 20 kHz
1.05 V
>20 kHz - 100 kHz
3.81 V
Specifications are for sine wave input > 5% of range for 100 mV – 100 V ranges, >15% for 300 V range, with High AC filter selected.
Volt-hertz product is limited to 1.5x10
7
V•Hz.
Over-range: 20% beyond range, except 300 V range.
Input Impedance: 1 MΩ  2% in parallel with < 100 pF.
