14
A.
B.
Connect a Large T-Joiner (G4) to the larger
end of a Large Top Rail (G2), and connect
a T-Joiner (G5) into the other.
Repeat for the 1 remaining Large Top Rail.
13
STEP
Attach the completed Large Top Rails to the top of the Upper
Frame Tubes.
Note: If you have accessories, make sure to face the smaller
ends of the Top Rail to the side where you will attach those
accessories.
14
STEP
G2
G4
G5
Place a Large T-Joiner (G4) and a T-Joiner (G5) at the
top of each Upper Frame Tube. Turn the T-Joiners and
Large T-Joiner to face inwards.
Insert the Large Top Rail (G2) tube through the loops
at the top of the Cargo Net. Insert the ends into the
T-Joiners
A.
B.
A.
B.
G2
G4 G5
Note:
If you have assembled
the Cargo net follow these
steps.
