VWR 5000 Advanced - CONTROL PANEL - ADVANCED ORBITAL SHAKER

A.
B.
EN
The front panel of the Advanced Orbital Shaker contains all the controls and displays
needed to operate the unit.
A. Standby button/standby indicator light: The standby indicator light will
illuminate when the unit is plugged in. The unit will be in standby mode. Press the
standby button to start the speed and time functions. The standby indicator light
will shut off. Press the standby button again and the unit will once again be in
standby mode.
B. Speed display: Displays the speed of the shaker.
C. Up/down arrows: For set-point control. On/off button starts/stop shaking function.
D. Time display: Displays accumulated time (continuous mode) or how much time
is remaining (timed mode). The display range is from 0 to 9999 minutes in one (1)
second increments. The display will indicate minutes and seconds until the timer
reaches 99 minutes and 59 seconds (99:59), then the display will automatically
display minutes up to 9999.
E. Up/down arrows for setpoint control. On/off button starts/stops the timer function.
ConTrol Panel - advanCed orbITal shaker
C.
D.
E.
