W Box 0E-81TMD - Appearance Description

10
Appearance Description
No.
Description
1
Indicator turns red when DVR is powered up.
2
Indicator lights in red when data is being read from or
written to HDD.
3
Indicator blinks blue when network connection is
functioning properly.
No.
Description
1
VIDEO IN
2
VIDEO OUT
3
HDMI Interface
4
VGA Interface
5
AUDIO IN, RCA Connector
6
AUDIO OUT, RCA Connector
7
LAN Network Interface
8
USB Interface
9
GND
10
12VDC Power Input
