Wabtec Microphor MICROFLUSH LF-210 - LF-210 Rough-In Dimensions; LF-210 Rough-In: Downward Discharge; LF-210 Rough-In: Rear Discharge; LF-210 Rough-In: Remote Flush

MICROFLUSH Toilet Manual 12 March 2005
LF-210 ROUGH-IN DIMENSIONS NOTE: All dimensions may vary ½” ±
16.5"
20.5"
8"
3.38"
13.25 "
AIR HOOK-UP 1/4" COPPER TUBING
COMPRESSION FITTING TO AIR SUPPLY
14.5"
7.6"
15.15"
WATER HOOK-UP
1/2" STRAIGHT
PIPE THREAD
TOILET DISCHARGE
1-1/2" PIPE SIZE (IPS)
TO ACCOMODATE
FLOOR FLANGE
CUTOUT AT REAR
26.5"
Elongated
3.38"
11.25"
13"
22"
MOUNTING
HOLES (4)
L
C
.75"
8.6"
15.15"
2.19"
TOILET DISCHARGE
1-1/2" SLIP/HUB
PIPE SIZE (IPS)
1.12"
Rear Discharge
Downward Discharge
24.5"
Round
File: 210r-spec
Remote Flush Rough-In
THE MAXIMUM WATER LINE DISTANCE BETWEEN THE TOILET AND THE REMOTE FLUSH ASSY IS SIX (6) FEET.
CUSTOMER WATER
SUPPLY CONNECTION
3/4" HOSE BARB
9.6"
3.25"
8.4"
VALVE ASSEMBLY
CUSTOMER AIR
SUPPLY CONNECTION
1" DIA. HOLE REQUIRED
THRU WALL (.38“ min/.75” max).
OPTIONAL WALL BOX KIT,
P/N 91870
PUSH TO FLUSH
5.25"
3.25"
FLUSH ACTIVATOR
Top View
BLEED-OFF
ASSEMBLY
INSTALL THE FLUSH
ASSEMBLY WITH
THE BASE OF THE
VACUMM BREAKER
6" Min. ABOVE THE
RIM OF THE TOILET.
THE AIR AND
WATER LINES ARE
PRE-INSTALLED.
