13F-001
5 6
HANGING THE FAN 07
1. Align downrod and motor collar holes, re-insert
pins and screws.
2. Slip up canopy and canopy screw cover. Re-install hanger ball
with cross pin in correct place.
1. Seat all into the mounting bracket. Rotate until ball drops
and locks into hanger bracket screw.
2. Secure safety cable to structure.
