WAC Lighting MOCHA - Package Contents; Main Fan Components; Included Accessories and Parts

9F-001
NOTE: ** denotes nish code of fan
1
10
7
3
4
9
15
6
5
14
2
8
11
12
13
Blade Collector
Ring
Canopy Ring
RPL-CAN-RND-**
Adapter Plate
(Optional)
Luminaire Cover
RPL-F001-COVER-**
Coupling
Cover
Safety Cable
5.4mm Spring
Washers (2pcs)
Safety Cable
5/32” Spring
Washers (2pcs)
Safety Cable
10 x 4mm x 0.8
Flat Washers (2pcs)
Hardware Bag
RPL-F001-PARTS
Hanger Bracket
8 x 3/4 Machine
Screws (2pcs)
Hanger Bracket
12 x 11W x 2 Self-
Tapping Screws (2pcs)
Blade Arm & Blade
1/4” x 18mm Blade
Screws (10pcs)
Blade Arm & Blade
Blade Press Plates (3pcs)
Canopy
RPL-CAN-RND-**
Motor Housing
Fan Blade
RPL-F001-54-
**
Remote Control
RC20-WT
PACKAGE CONTENTS 04
Downrod
Assembly
RPL-HGR-ASM-**
Mounting
Bracket
RPL-HGR-ASM-**
Glass Shade
(Optional)
RPL-F001-GLA
Luminaire Module
(Optional)
F-001-LED-**
Receiver
F-R3-001-054
