10 Use and operation
32
10.3 Changing tools
General notes
You can change the tool without additional tools.
Notes on using tools
Only use tools with the following properties:
The tool must be suitable for the tool holder.
The tool end must be undamaged.
The tool must be sufficiently sharp to avoid impact damage.
The tool must be suitable for the intended application.
Inserting tool
1. Clean tool end.
2. Swivel out handle on the tool holder.
3. Turn the tool into the position which is most suitable for the intended work.
4. Push tool into the tool holder as far as it will go.
5. Press the handle on the tool holder.
6. Check to see if the tool is locked by pulling on the tool.
Item Designation Item Designation
1 Handle 3 Tool holder
2 Guide cylinder 4 Tool
