Wacker Neuson BPS1030A - Page 52

Technical Data
13.3 BPS Honda
Type BPS1030Aw BPS1030A
Material number machine 5100058916 5100059658
Height [mm] 663 663
Underclearance [mm] 663 663
Operating weight [kg] 56 53
Nominal power** [kW] 2,6 2,6
Rated speed [1/min] 3600 3600
Operating temperature range [°C] -15 - +45 -15 - +45
Storage temperature range [°C] -15 - +40 -15 - +40
Sound pressure level at operator station LpA [dB(A)] 92 92
Sound power level LWA, measured [dB(A* 104 104
Sound power level LWA guaranteed [dB(A)] 105 105
Vibration total value ahv [m/s2] 4.6 4.6
Measurement uncertainty of the total vibration value
ahv [m/s2]
0.5 0.5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
Type BPS1135Aw BPS1135A
Material number machine 5100059657 5100059662
Material number engine 5100045994 5100045994
Centrifugal force [kN] 11 11
Vibrations [Hz] 98 98
Vibrations [1/min] 5880 5880
Area output* [m2/h] 546 546
Flow [m/min] 26 26
Gradeability [%] 36,4 36,4
Length (drawbar in working position) [mm] 930 930
Width [mm] 350 350
Height [mm] 663 663
Underclearance [mm] 663 663
Operating weight [kg] 63 61
Nominal power** [kW] 2,6 2,6
Rated speed [1/min] 3600 3600
Operating temperature range [°C] -15 - +45 -15 - +45
Storage temperature range [°C] -15 - +40 -15 - +40
Sound pressure level at operator station LpA [dB(A)] 93 93
Sound power level LWA, measured [dB(A* 104 104
Sound power level LWA guaranteed [dB(A)] 105 105
Vibration total value ahv [m/s2] 4.5 4.5
Measurement uncertainty of the total vibration value
ahv [m/s2]
0.5 0.5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
52 Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 |
Version: 5 | [en]
