Operation
T01092en.fm 19
7. Operation
7.1 Start preparation
Before you start the engine, check the following:
f Fuel level – the tank should be at least half full.
f Motor oil level.
f Air filter.
f Fuel lines for leaks.
f External screw connections for tightness.
7.2 Starting the engine
f Open the fuel tap (a1).
f Cold start: Close the choke (d2).
Warm start: Open the choke (d1).
Note: The engine is hand warm or hotter with warm start.
f Set the engine switch to "ON" (b2).
f Push the throttle lever to the left (c2).
f Pull out the starter rope (e) until compression resistance can be felt and then
let it roll back in again.
f Pull the starter rope with force, but not suddenly.
The engine starts.
f Let starter rope slowly roll back in.
f Open the choke while the engine is warming up.
f Open the throttle lever completely for operation (c1).
a1
a2
b2
b1
c1
c2
c3
d2
wc_gr000655
e
d1
