Maintenance
T01093en.fm 26
8.6 Checking exciter V-belt
f Remove V-belt protector.
f Check exciter V-belt for signs of damage. Replace damaged exciter V-belts.
f Check tension.
f Screw the V-belt protector back on and use a torque wrench to tighten it to
10 Nm.
8.7 Changing exciter V-belt
f Remove V-belt protector.
f Remove 3 screws on engine V-belt disc.
f Remove outer half of V-belt disc.
f Change exciter V-belt.
f Press the V-belt downward into the exciter box and thread the V-belt pulley.
Note: Attach the V-belt within both roll pins.
f Attach clutch drum and tighten with 3 screws to 10 Nm.
Note: Turn the clutch drum in the process to avoid pinching the V-belt.
f Remount V-belt protector. Tighten screws with a torque wrench to 10 Nm.
8.8 Checking / filling hydraulic oil level
f Vertically set guide handle head and lock into place.
f Press the control handle in the forward movement position.
f Remove any dirt around the filler hole.
f Open the filler hole (1).
f Check: Oil level must reach upper edge of the gear.
f If necessary, fill with new hydraulic oil through the filler hole up to the upper
edge of the gear (see chapter Technical data for oil type).
f Close the filler hole and tighten.
Note: The hydraulic control is self-bleeding.
