T00676GB
22
MAINTENANCE
Exciter
Check oil level:
1. Position vibration plate horizontally.
2. Open filler bore (16).
3. The oil level must reach the start of the thread of the filler bore (16).
4. If necessary, pour in HD brand oil SAE 10 W 40 through filler bore (use funnel).
5. Close filler bore (16).
Lower and of thread
Changing the oil:
1. Open filler bore (16).
2. Tilt vibration plate and keep it tilted until the oil has run out.
3. Place vibration plate in horizontal position.
4. Pour in 0,75 l HD brand oil SAE 10 W 40 through the filler bore (16).
5 Close filler bore (16).
☛WARNING! Do not pour in too much oil!
