BS 600/BS 700 Technical Data
wc_td000004gb.fm 21
4.2 Sound Measurements
The required sound specification, Paragraph 1.7.4.f of 89/392/EEC
Machinery Directive, is:
the sound pressure level at operator's location (L
pA
) = 90 dB(A).
the guaranteed sound power level (L
WA
) = 108 dB(A).
These sound values were determined according to ISO 3744 for the
sound power level (L
WA
) and ISO 6081 for the sound pressure level
(L
pA
) at the operator's location.
4.3 Vibration Measurements
The operating hand/arm vibration level, measured per the
requirements of enclosure 1, Paragraph 2.2 or 3.6.3 of the EC-
Machine Regulations, is approximately 15 m/s
2
.
The weighted effective acceleration value was determined according
to ISO 8662 Part 1.
The sound and vibration measurements were obtained with the
machine operating on crushed gravel at nominal engine speed.
4.4 Dimensions
mm (in.)
