BS 600/BS 700 Maintenance
wc_tx000024gb.fm 29
6.5 Carburetor Adjustments
See Graphic: wc_gr000049
Refer to Technical Data for correct idle and operating rpm. For best
accuracy, use a tachometer when making carburetor adjustments.
6.5.1 Start engine and allow it to warm up to operating temperature.
6.5.2 Set engine idle speed with engine running at idle and choke (a) fully
open. Adjust idle speed screw (b), in or out, to obtain correct idle
speed.
CAUTION: DO NOT turn the adjusting screw in too tight or you may
damage the carburetor.
6.6 Storage
6.6.1 Drain fuel from tank.
6.6.2 Start engine and run until remaining fuel is used.
6.6.3 Remove spark plug. Pour approximately 30 ml (1 oz.) of clean SAE
10W30 engine oil into cylinder through spark plug opening.
6.6.4 Pull starter rope slowly to distribute oil in engine.
6.6.5 Re-install spark plug.
wc_gr000049
a
b
