BS 600/BS 700 Operation
wc_tx000023gb.fm 23
5.4 To Start
See Graphic: wc_gr000053
5.4.1 Open fuel valve.
5.4.2 If the engine is cold, close choke (b1) on the carburetor.
Note: Occasionally, warm engines will need to be choked.
5.4.3 Move throttle control to ¼ to ½ of the full position (c3).
5.4.4 Pull the starter rope (a) until the engine starts, or attempts to start.
Note: First time use, engines recently serviced, run out of fuel or not
used for long periods of time may need the rope to be pulled more
times to move fuel to the carburetor.
5.4.5 Open choke (b2) on the carburetor as the engine warms up, or, if it
attempts to start, continue pulling the rope until it starts.
Note: A cold engine should be allowed to warm up at the idle position
(c2) for approximately one (1) minute. Failure to open the choke after
the engine attempts to start may cause flooding.
wc_gr000053
STOP
b1
b2
a
c1
c2
c3
c4
d
