Maintenance
T00963GB 49
Loosen the screws (13) and remove the covering cap (14).
Clean the sealing rings (15) with a small brush and check them for
damage.
Remove prefilter (17) from the filter cover.
Pull air filter insert (18) from the hood.
Remove the inner filter (16) from the intake opening.
Note:
Do not allow dirt to get into the carburetor!
Set the combination switch to “Choke“ or cover the carburetor with a
clean cloth.
