Maintenance
T00963GB 48
8.2 Cleaning the protective hood
Over time, the inside of the protective hood can become caked with
material residue (especially from wet cutting), which if allowed to
accumulate can hinder the free rotation of the cutting blade. For this
reason the hood must be cleaned out from tim to time.
Take off the cutting blade with spring washer and remove the
accumulated material from inside the hood with a strip of wood or
similar implement.
Clean the shaft and all disassembled parts with a cloth.
8.3 Cleaning/changing the air filter
Turn the cover lock (11) to the „Unlocked “ position and carefully
remover the filter cover (12).
Two sealing rings (54/15) are located between the filter cover (12) and
the covering cap (54/14).
52
NOTE: See “Fitting cutting blades“ for
assembly of blades.
53
