TD00400GB
7
TECHNICAL DATA
DPU 2950 DPU 2960 DPU 2970
Item no. 0007881 ... 0007883 ... 0007880 ...
Lowest working height mm: 790
Size of base plate (width x length) mm: 500 x 700 600 x 700 700 x 700
Operating weight kg: 192 198 203
Power transmission From drive engine via
centrifugal clutch and V-belts
direct to exciter
Exciter
Vibrations min
-1
(Hz): approx. 5400 (90)
Multigrade oil SAE 10 W 40
Drive motor Air-cooled single-cylinder 4 stroke diesel engine
Piston displacement cm
3
: 353
Engine speed min
-1
: 2850 + 100
Oil SAE 10 W 40
Fuel Diesel
Fuel consumption l/h: 1,2
Tank capacity l: 5
The required sound specifications, called-for by the EC-Machine Regulations per Appendix 1, Paragraph
1.7.4.f, are
- sound pressure level at the operator's location L
pA
= 95 dB(A)
The sound values were determined according to ISO 3744 for the sound power level (L
wA
) and, alternately,
ISO 6081 for the sound pressure level (L
pA
) at the operator's location.
The weighted effective acceleration value, determined according to ISO 8662, Part 1, is 7,5 m/s
2
.
The sound and vibration measurements were carried out and obtained with the machine working on crushed
gravel at nominal engine speed.
