9 Maintenance
100_0202_mt_0011.fm 47
3. If necessary, fill with engine oil with a funnel until the upper mark of the oil-level dipstick is reached –
for the oil specification and quantity, see the Technical Data chapter.
4. Put the cover back on the oil filler opening and press firmly.
5. Wipe away any spilled oil.
9.4.4 Replace motor oil
Drain the engine oil and replace the oil filter
1. Open the front protective hood.
2. To protect the floor from leaking oil, cover the working surface with an impermeable foil.
3. Place collecting container under the oil drain plug.
4. Loosen oil drain plug.
5. Place a sufficiently large collecting container under the oil filter.
6. Unscrew and remove oil filter – when unscrewing, collect any leaking oil.
7. When the oil has completely drained, screw in the oil drain plug and tighten.
8. Screw in a new oil filter and tighten with 20 Nm.
Fill motor oil
1. Remove dirt accumulation in the area of the oil filler opening.
2. Remove cover of the oil filler opening.
3. If necessary, fill with oil until the upper mark of the oil-level dipstick is reached – for oil specification
and amount of oil, see Technical Data chapter.
4. Put the cover back on the oil filler opening and press firmly.
5. Wipe away any spilled oil.
6. Briefly allow the engine to run.
7. Switch off engine.
8. Check oil level and top off if necessary.
NOTICE
Dispose of oil in accordance with the applicable provisions for environmental protection.
NOTICE
Change oil in lukewarm engine so that the oil can drain completely.
Item Designation Item Designation
1 Cover of the oil filler opening 3 Oil filter
2 Oil-level dipstick 4 Oil drain plug
NOTICE
Dispose of oil in accordance with the applicable provisions for environmental protection.
