5-2 BA DT10 en - Edition 1.5 * * dt10b510.fm
Maintenance
Maintenance strut for high-tip skip
Careful when performing maintenance on or under the skip, and in general
when performing maintenance with the skip tilted out –
Accident hazard!
☞Use the maintenance prop
Proceed as follows to attach the maintenance prop:
☞Raise tipping trailer
☞Empty front tip skip
☞Raise safety rod A
➥The skip is blocked in the raised position
☞Remove the safety pin and the stud from opening B and insert them in opening C
➥The skip is blocked in the raised position
Fig. 60: Maintenance prop
B
C
A
